057 86 64506
Technical data
Energy class
| Version | Front facing |
|---|---|
| Nominal power (kW) | 15 |
| Heating power range (kW) | 7-18 |
| Thermal Efficiency (%) | 80.2 |
| Flue gas temperature (oC) | 288 |
| Max billet length (cm) | 50 |
| Minimum required active area of inlet grilles (cm2) | ≥800 |
| Minimum required active field of outlet grilles (cm2) | ≥1000 |
| diameter of the flue gas outlet | 200 |
| Color | Black |
| Additional closing | No |
| Base material | Steel, Cast iron |
| Door opening | Left |
| Energy class | A |
|---|---|
| EEI | 106 |
| Seasonal Energy Efficiency (%) | 70 |
| Heat output for space heating (kW) | 15 |
| CO emission (at 13% O2) ≤ given in % | 0.111 |
| CO emission (mg/m3) | 1388 |
| Pollen emission (mg/m3) | 14 |
| NOx emission (mg/m3) | 104 |
| OGC emission (mg/m3) | 95 |
| Flue gas mass flow (g/s) | 11.8 |
| Certificates | Ecodesign |
|---|
| Equipment | Air intake - additional option, Ashpan, Decorative glass |
|---|---|
| FRONT | Steel front with painted glass |
| Fuel type | Seasoned deciduous wood (humidity ≤20%) |
| Width (cm) | 65.2 |
|---|---|
| Height (cm) | 81 |
| Depth (cm) | 43.5 |
| Weight (kg) | 140 |
