Specification
Nominal power (kW) 10
Thermal Efficiency (%) 75
Energy class Energy card (UE) 2015/1186![]()
Certificates Ecodesign
Weight (kg) 160
Technical data
General data
| Nominal power (kW) | 10 |
|---|---|
| Heating power range (kW) | 8,5 - 12,5 |
| Thermal Efficiency (%) | 75 |
| Flue gas temperature (oC) | 289 |
| Max billet length (cm) | 35 |
| COLOUR | Black |
| CLOSING | No |
| OPTIONAL EQUIPMENT | Boiler |
| Door opening | Left |
| Materials | Cast iron |
| diameter of the flue gas outlet | 146 |
| Max working pressure (bar) | 2 |
Energetic efficiency
| Energy class | A |
|---|---|
| EEI | 98 |
| Seasonal Energy Efficiency (%) | 65 |
| Heat output for space heating (kW) | 8 |
| Average power from water (kW) | 2 |
| CO emission (at 13% O2) ≤ given in % | 0.148 |
| CO emission (mg/m3) | 1856 |
| Pollen emission (mg/m3) | 14 |
| NOx emission (mg/m3) | 108 |
| OGC emission (mg/m3) | 78 |
| Flue gas mass flow (g/s) | 11.5 |
Certifications / Compliance
| Certificates | Ecodesign |
|---|
Additional information
| Equipment | Ashpan |
|---|---|
| FRONT | Cast iron front with ceramic glass |
| Fuel type | Seasoned deciduous wood (humidity ≤20%) |
